Hollyland Mars 400S PRO SDI/HDMI Wireless Video Transmission System

Hollyland Mars 400S PRO SDI/HDMI Wireless Video Transmission System

Brand:

Hollyland

Add up to 1080p60 wireless video transmission to your gimbal, mirrorless, or DSLR camera rig using the lightweight Mars 400S PRO SDI/HDMI Wireless Video Transmission System from Hollyland. The transmitter provides HDMI and SDI inputs and the receiver offers SDI and HDMI outputs. It features extremely low 0.1s latency

Add to Wishlist

... people are viewing this right now

Category: Video Transmission Systems Brand: Hollyland

Description

Enhance your gimbal, mirrorless, or DSLR setup with the Hollyland Mars 400S PRO SDI/HDMI Wireless Video Transmission System.
This lightweight system supports up to 1080p60 video transmission, featuring HDMI and SDI inputs on the transmitter and HDMI and SDI outputs on the receiver.
It boasts a minimal 0.1s latency with a line-of-sight range of up to 400′ to the receiver and 300′ to the Hollyview app.

Key Features:

High-Resolution Transmission: Delivers up to 1080p60 SDI or HDMI video.
Long Range & Low Latency: 400′ range to receiver, 300′ to app, with 0.1s latency.
Real-Time Monitoring: Use the Hollyview app for iOS/Android to monitor and live stream video.
Versatile Transmission: Simultaneously connect to one receiver and two apps, or up to four apps.
Flexible Power Options: Powered by L-series battery, DC adapter, or USB Type-C.

The Mars 400S PRO includes two external antennas per unit for a strong signal,
a bright OLED display for easy configuration, and multiple fan modes to manage heat.
The compact design features a 1/4″-20 mounting thread for versatile mounting options.

Additional information

Wireless Range	400' / 121.92 m (Line-of-Sight) 300' / 91.4 m (Line-of-Sight)
channel Bandwidth	20 MHz
Frequency Range	US: 5 GHz
Latency	0.1 sec
RF Power	< 21 dBm
RF Sensitivity	-80 dBm
Transmitter Antenna Ports	2x RP-SMA Male
Receiver Antenna I/O	2x RP-SMA Male
Transmitter Video Connectors	1x BNC (3G-SDI / HD-SDI) Input 1x HDMI Input
Receiver Video Connectors	1x BNC (3G-SDI) Output 1x HDMI Output
Transmitter Other I/O	1x USB-C
Receiver Other I/O	1x USB-C
Embedded Audio	HDMI/SDI
Video Format	SDI/BNC: 1080p at 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps 1080i at 50, 59.94, 60 fps 1080PsF at 23.98, 24, 25 fps 720p at 50, 59.94, 60 fps HDMI: 1080p at 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps 1080i at 50, 59.94, 60 fps 720p at 50, 59.94, 60 fps 576p at 50 fps 480p at 60 fps
Transmitter Panel Type	OLED
Receiver Panel Type	OLED
Transmitter Battery Support	1x Sony L-Series / NP-F Type
Receiver Battery Support	1x Sony L-Series / NP-F Type
Transmitter Battery Support 1x Sony L-Series / NP-F Type Receiver Battery Support 1x Sony L-Series / NP-F Type Transmitter Power I/O	1x Barrel (6 to 16 VDC up to 2 A) Input 1x USB-C (5 VDC up to 2 A) Input
Receiver Power I/O	1x Barrel (6 to 16 VDC up to 2 A) Input 1x USB-C (5 VDC up to 2 A) Input
Transmitter Power Consumption	Power Supply: 6 to 16 VDC (11 W)
Receiver Power Consumption	Power Supply: 6 to 16 VDC (7 W)
Transmitter Mounting	1x 1/4"-20 Female 1x Cold Shoe
Receiver Mounting	1x 1/4"-20 Female 1x Cold Shoe
Transmitter Dimensions	4.3 x 2.8 x 1.32" / 11 x 7.2 x 3.35 cm
Receiver Dimensions	4.3 x 2.8 x 1.32" / 11 x 7.2 x 3.35 cm
Transmitter Weight	0.5 lb / 206 g
